Adaptador de cargador para vehículos eléctricos de 16 A/32 A, tipo 2 a tipo 2 (T111-0025)

Model.T111-0004-2
Corriente nominal: cargador de vehículos eléctricos tipo 2 a tipo 2 de 16 A o 32 A (5 M)
Material del cable: TPU
Tensión de funcionamiento: 250 V o 415 V
Vida útil mecánica: Conexión/desconexión sin carga > 10000 veces
Fuerza de inserción acoplada: >45N<80N
Impacto de la fuerza externa: puede soportar una caída de 1 m y el paso de un vehículo de 2 t por encima de la presión.
Resistencia de aislamiento: > 1000 MΩ (500 V CC)
Aumento de la temperatura terminal:<50K
Tensión de resistencia: 2000 V
Resistencia de contacto: 0,5 mΩ máx.
Casquillo de contacto: Aleación de cobre, chapado en plata.
Pasador: Aleación de cobre, plata + termoplástico en la parte superior
Temperatura de funcionamiento: -30 ℃ ~ +50 ℃
Especificaciones del cable:
16A monofásico 3*2,5mm2+2*0,5mm2
16A trifásico 5*2,5mm2+2*0,5mm2
32A monofásico 3*6mm2+2*0.5mm2
32A trifásico 5*6mm2+2*0.5mm2
Color del cable: negro
Norma de carga: IEC62196-2
Descripción

Basic Info.

Model NO.:T111-0016-2
Power Source:Electric Power
Brand:Customerized
Application:Electric Appliance
Transport Package:Zipper Bag
Specification:32A
Trademark:TOKING
Origin:China
HS Code:8504401990
Production Capacity:70000/M

Product Description

Product Description

Rated Current: 32A  Type2 EV charger (5M)
Operating Voltage: 250V
Mechanical life: No-load plug in/pull out> 10000 times
Coupled insertion force: >45N<80N
Impat of external force: can afford 1 m drop and 2t vehicle run over pressure
Insulation resistance:> 1000 MΩ(DC500V)
Terminal temperature rise: <50K
Withstand voltage: 2000V
Contact Resistance: 0.5mΩ Max
contact bush: Copper alloy, silver plating
Operating temperature: -30oC ~+ 50oC
Cable specification: 32A 3*6mm2+2*0.5mm2
Cable color: black
Charging standard: IEC62196-2

Company Profile

Found date: 2003
Plant area:4 Buildings 24000m2
Employee: 400(Technician:30 QE:20)
Main products: Inverter generator ,DC to AC Inverter(car inverter,modified inverter, pure sine wave inverter, soft start inverter,)BATTERY CHARGER, STRIP INVERTER ECT....
Certificate:ISO 9001,BSCI
Product certificate: CE‐EMC/LVD,RoHS,TUV,E‐Mark,ETL,RCM(C‐TICK)
Monthly output: 100000pcs

Electric Car 32A Type2 EV Charger Electric Cable Plug Adapter Fast Charging Portable Electric Vehicle Charging

Workshops

Electric Car 32A Type2 EV Charger Electric Cable Plug Adapter Fast Charging Portable Electric Vehicle Charging
Electric Car 32A Type2 EV Charger Electric Cable Plug Adapter Fast Charging Portable Electric Vehicle Charging Electric Car 32A Type2 EV Charger Electric Cable Plug Adapter Fast Charging Portable Electric Vehicle Charging

Quality control

Electric Car 32A Type2 EV Charger Electric Cable Plug Adapter Fast Charging Portable Electric Vehicle Charging

Certifications

Electric Car 32A Type2 EV Charger Electric Cable Plug Adapter Fast Charging Portable Electric Vehicle Charging

FAQ

1,Q:What is the MOQ?
A: It depend on the products model .in gernarally the MOQ of formal order is 300pcs.Mostly MOQ can be discussed .

2, Q: What is the payment terms?
A: T/T ,LC ,Western union ,Paypal.

3,Q: How to order?
A: Step1:Pls tell us what model and quantities you need;
 Step2:We will send you price and make PI for you to confirm the order details;
 Step3:when confirmed the details ,you can arrange the deposit and we will arrange production .
Step4:When goods finished ,we will deliver them within the stipulated time

4, Q: When will make delivery ?
 A: Sample order :within 7working days .
Formal order: 30-45days .
OEM order:50-60days

5,Transportation
 Transported by Sea freight ,Air freight ,DHL,UPS,EMS.FEDEX ,TNT,Air

6,Q:What is the Warranty ?
 A: 1year warranty for the products ,and Exceed the 12months ,we can provide the spare parts .

7,Q: Do you have certificates ?
 A:Our factory have ISO9001, BSCI.And Products with the CE,ROHS,E-MARK,ReaCH,ETL,SAA

Our products are exported to North America,Australia,Middle East,Africa,Southeast of Asia,South America and Europe.

We are positive to enlarge our markets in other countries.

Welcome your inqury!
